| 外壳材质 | Housing Material | 金属 |
| 输出轴承形式 | Bearing at output | 滚珠轴承 |
| 径向负载（N） | Radial load (10mm from flange) | ≤120 |
| 轴向负载（N） | Shaft axial load | ≤80 |
| 静态主轴最大承受压入力 | Shaft press fit force max Static （N） | ≤500 |
| 径向间隙（mm） | Radial play of shaft | ≤0.03 |
| 轴向间隙（mm） | Thrust play of shaft | ≤0.1 |
| 背隙（无负载时） | Backlash at no-load | ≤1.5° |
| 减速比 | 额定允许负载（NM） | 瞬间允许负载（NM） | 效率（%） | 长度（MM） | 重量（G） | 减速比级数 |
|---|---|---|---|---|---|---|
| 1/4 | 1.0 | 3.0 | 81% | 32.5 | 170 | 1 |
| 1/6 | 1.0 | 3.0 | 81% | 32.5 | 170 | 1 |
| 1/15 | 4.0 | 12 | 72% | 46.3 | 207 | 2 |
| 1/18 | 4.0 | 12 | 72% | 46.3 | 207 | 2 |
| 1/21 | 4.0 | 12 | 72% | 46.3 | 207 | 2 |
| 1/25 | 4.0 | 12 | 72% | 46.3 | 207 | 2 |
| 1/36 | 4.0 | 12 | 72% | 46.3 | 207 | 2 |
| 1/54 | 8.0 | 25 | 65% | 60.1 | 267 | 3 |
| 1/65 | 8.0 | 25 | 65% | 60.1 | 267 | 3 |
| 1/73 | 8.0 | 25 | 65% | 60.1 | 267 | 3 |
| 1/81 | 8.0 | 25 | 65% | 60.1 | 267 | 3 |
| 1/90 | 8.0 | 25 | 65% | 60.1 | 267 | 3 |
| 1/112 | 8.0 | 25 | 65% | 60.1 | 267 | 3 |
| 1/126 | 8.0 | 25 | 65% | 60.1 | 267 | 3 |
| 1/155 | 8.0 | 25 | 65% | 60.1 | 267 | 3 |
| 1/216 | 10.0 | 30 | 65% | 60.1 | 267 | 3 |
*以上仅为代表产品，派生产品可按客户需求定制。
*负载与转速有关，具体数据需参考实际情况。
